PCMCIA Frameless Kit
Series 9180
DIMENSIONS
Typical PCB Layout
51.00 (2.008)
2.56 (0.101) MAXIMUM
COMPONENT HEIGHT
Typical Cross Section View
54.00±0.10 (2.126±0.004)
51.00 (2.008) PCB WIDTH
2 PADS
0.80 x 0.80
(0.031 x 0.031)
?1.00 PTH
2 POSITIONS
0.50 x 45o
(0.020 x 45o)
TYP
R0.50
(0.020)
71.20
(2.803)
77.70
(3.059)
TYP
PCB
OFFSET
0.4 (0.016)
0.96 (0.038) MAXIMUM
COMPONENT HEIGHT
0.8 (0.031)
PCB
ALL DIMENSIONS SHOWN ARE REFERENCE
DIMENSIONS UNLESS TOLERANCED
0.20
5.00 (0.197)± 0.00
82.30
(3.240)
67 PITCHES @ 0.635 = 42.55
(0.025 = 1.675)
Typical PCB Layout - Extended Kit
SUPPORT AREA
68 PADS 0.45 x 1.15
(0.018 x 0.045)
5.20
45.00 (1.772)
SUPPORT SIDE
OF PCB
POSITION 34 POSITION 35
1.00
(0.205)
32.80 (1.291)
POSITION 68 POSITION 1
R0.50 TYP
1.62
(0.064)
(0.039)
1.50
(0.059)
43.87 (1.727)
47.19 (1.858)
51.00 (2.008)
4.00
(0.157)
SUPPORT AREA
UPPER SIDE
OF PCB
2.50 (0.098)
SUPPORT AREA
BOTH SIDES
OF PCB
Typical Cross Kit Section - Extended Area
5mm Version
2.0 (0.079) MAXIMUM
COMPONENT HEIGHT
0.40 (0.016)
PCB OFFSET
113.40
(4.465)
TOTAL BOARD AREA
45.00 (1.772) PCB WIDTH
0.80 (0.031)
86.00
(3.386)
4950mm 2
0.4 (0.016) MAXIMUM
COMPONENT HEIGHT
5mm HEIGHT EXTENSION
PCB THICKNESS
57.50
(2.264)
11.10
(0.437)
67 PITCHES @ 0.635 = 42.55
(0.025 = 1.675)
68 PADS 0.45 x 1.15
(0.018 x 0.045)
Typical Cross Kit Section - Extended Area
6.9 (0.272) MAXIMUM 10mm Version
COMPONENT HEIGHT
4.60
(0.181)
POSITION 34 POSITION 35
POSITION 68 POSITION 1
R0.50 TYP
43.87 (1.727)
1.62
(0.064)
47.19 (1.858)
51.00 (2.008)
All dimension are shown in
0.4 (0.016) MAXIMUM
COMPONENT HEIGHT
45.00 (1.772) PCB WIDTH
0.80 (0.031)
PCB THICKNESS
millimeters (inches)
21
